NA346

Fanless Ultra Compact Network Appliance with Intel® Celeron® Processor N3350 and up to 4 LAN for Entry Level SD-WAN, VPN

  • Small form factor with fanless and noiseless design
  • Intel® Celeron® processor N3350 (Apollo Lake)
  • One DDR3L-1866 SO-DIMM for up to 8GB of memory
  • Four 10/100/1000 Mbps Ethernet ports (Intel® i211)
  • PCI Express Mini Card slot for optional
  • Suitable for IoT security applications

The NA346, a 4-LAN fanless network appliance platform designed in a small form factor, is powered by the Intel® Celeron® processor N3350 featuring the lowest Thermal Design Power (TDP) of 6W to meet the specific configurations of low-power requirement. The cutting-edge NA346 offers two mini-PCIe slots and a SIM socket supporting 3G/4G/LTE communications and connectors to 5G modules. Space limitation is one of the constraints in today’s industrial environment. Axiomtek’s ultra-small NA346 can be easily installed in narrow spaces. Featuring fanless operation, this network security appliance is perfect to be used in noise-sensitive environments. The NA346 supports one DDR3L-1600 SO-DIMM slot with up to 8GB of system memory and also offers one mSATA for storage. Under its small form factor, the network communication platform comes with four 10/100/1000 Mbps LAN ports using the Intel® i211 Ethernet controller. Other I/O interfaces include one serial console port, two USB 3.0 ports and one HDMI port. To ensure reliable operation, the NA346 supports a screw-type DC jack and a power button with LED, providing users with a more elegant and reliable product. It is compatible with Win 10 and Linux (Yocto project) operating systems.

Form Factor
  • Small form factor
  • Desktop
CPU
  • Intel® Celeron® processor N3350 (Apollo Lake)
Chipset
  • SoC integrated
System Memory
  • 1 x DDR3L-1866 SO-DIMM, up to 8GB non-ECC/ECC memory
BIOS
  • AMI
Ethernet
  • 4 x 10/100/1000 Mbps Ethernet (Intel® i211)
LAN Bypass
  • LAN Bypass (optional)
LAN Module
  • N/A
Storage
  • 1 x mSATA (Half size)
  • 1 x mSATA (Full size)
Expansion
  • 1 x Half-size PCI Express Mini Card slot with SATA/USB signal
  • 1 x Full-size PCI Express Mini Card slot with SATA/USB signal (PCIe signal co-layout with Eth4)
I/O Interface
  • 1 x RS-232 (RJ-type)
  • 4 x RJ-45
  • 2 x USB 3.0
  • 1 x HDMI
Power Supply
  • 12V DC
LCM Module
  • N/A
Operating Temperature
  • 0°C to +40°C (+32°F to +104°F)
Dimensions
(H x W x D)
  • 33.5 x 146 x 118.2 mm (1.32" x 5.75" x 4.65")
Weight (net/gross)
  • 0.62 kg (1.37 lb)/1.3 kg (2.87 lb)
EOS Support
  • Win 10, Linux (Yocto project)
Certifications
  • FCC class B/CE class B
  • NA346-D4G-N3350-US w/o LBP (P/N-E26E346100)
  • SFF fanless network appliance with Intel® Celeron® processor N3350 for entry-level SD-WAN, VPN and security gateway
  • 5916E552000E
  • DB9F-RJ-45 1.8M console cable for Cisco
