P1177E-871

17" SXGA TFT Expandable Industrial Touch Panel Computer with 3rd Gen Intel® Core™ i7/i5/i3, Celeron®, Pentium® & Xeon® P

  • 17" SXGA TFT LCD display
  • LGA1155 socket 3rd gen Intel® Core™ i7/i5/i3, Celeron®, Pentium® & Xeon® processor
  • Intel® C216 chipset
  • Less screw design for easy installation
  • 4 USB 3.0, 2 USB 2.0 and 4 COM ports
  • 2 PCIe x8 or PCI expansion slots
  • Built-in speakers and optional Wi-Fi 802.11 b/g/n module
  • Robust aluminum with IP65 compliant front bezel design

The P1177E-871 Panel PC support the high performance 3rd Generation Intel® Core™ i7, i5 and i3 processors in LGA1155 socket with the Intel® C216 chipset. The P1177E-871 has reserved two PCIe or two PCI slots to fulfill different application needs. Built around user-convenience, this all-in-one superior touch panel computer provides a screw-less chassis design. To withstand harsh operating environments, it provides protection with aluminum housing and IP65/NEMA 4 sealing and offers reliable performance and quality. With the new Intel® HD 4000 graphics engine, Axiomteks P1177E-871 can easily handle the demands of intensive graphical interfaces or 3D graphics. The high-performing, reliable, and user-friendly touch panel computers are best suited for factory automation, kiosk, and more industrial fields.

LCD Panel
  • 17" SXGA TFT LCD
  • 350 nits
  • 1280 x 1024 pixels
CPU
  • LGA1155 socket 3rd generation Intel® Core™ i7/i5/i3, Celeron®, Pentium® & Xeon® processor
Chipset
  • Intel® C216
System Memory
  • 2 x 204-pin SO-DIMM DDR3-1333/1600 up to 16 GB
BIOS
  • AMI
COM
  • 2 x RS-232
  • 1 x RS-232/422/485 with 5V & 12V
  • 1 x RS-232 with 5V & 12V
USB
  • 4 x USB 3.0
  • 2 x USB 2.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® 82579LM/82583V)
Display
  • 1 x DVI-I
  • 1 x HDMI
Audio
  • Mic-in/Line-out
Storage
  • 1 x 3.5" or 2 x 2.5" SATA HDD (7-9.5 mm height)
Expansion
  • 2 x PCIe x8 or 2 x PCI
Others
  • Built-in speakers
  • Optional Wi-Fi 802.11 b/g/n module
Touchscreen
  • 5-wire resistive type
Front Bezel
  • Aluminum with IP65/NEMA 4 rugged protection
Power Supply
  • 100 ~ 240VAC, 270 W
Power Comsumption
  • 180 W
Watchdog Timer
  • 255 levels, 1~255 sec.
Operating Temperature
  • 0°C ~ +45°C (+32°F ~ +113°F)
Relative Humidity
  • 10% ~ 90% @ 40°C, non-considering
Vibration
  • 1.0G, 5-500Hz, random
Dimensions
(W x D x H)
  • 410 x 131 x 338 mm (16.14" x 5.16" x 13.3")
Weight (net/gross)
  • 8.2 kg (18.078 lb)/12 kg (26.46 lb)
Certifications
  • CE
EOS
  • Windows® XP/XPe, Windows® 7/8.1, Windows® Embedded 7/8
Mounting
  • VESA mount
  • Wall mount
  • Rack mount

Latest News

  • P1177E-871 w/ PCIe
  • 17" SXGA expandable industrial touch panel computer with LGA1155 socket 3rd generation Intel® Core™ i7/i5/i3, Xeon®, Pentium® & Celeron® processor, resistive touch screen and 2 PCIe x8 slot, 100~240 VAC
  • P1177E-871 w/ PCI
  • 17" SXGA expandable industrial touch panel computer with LGA1155 socket 3rd generation Intel® Core™ i7/i5/i3, Xeon®, Pentium® & Celeron® processor, resistive touch screen and 2 PCI slot, 100~240 VAC
  • 82211271000E
  • Wireless LAN kit
  • 82011750130E
  • 2 x 2.5" HDD kit
  • 8211770120E
  • VESA & wall mount kit
  • 82211770070E
  • Rack mount kit
  • 82211770110E
  • P1177E-871 DVD-RW kit
  • E981604011
  • ATC10 (VESA arm clamp type)
  • E981604012
  • ATW10 (VESA arm wall mount)
  • E221177116
  • PPC HA741L black stand (L)
  • Power cord (EU/US/UK/JP)
  •
