GOT810-316

LCD Panel	10.4" XGA TFT LCD 450 nits 1024 x 768 pixels
CPU	Intel® Celeron® processor N3350 2 cores (up to 2.4GHz)
Chipset	SoC integrated
System Memory	1 x 204-pin DDR3L-1600 SO-DIMM, up to 8GB
BIOS	AMI
COM	1 x RS-232/422/485 (default RS-232, M12 A-coded) 1 x RS-232 (M12 A-coded)
USB	2 x USB 2.0 via M12 connector
Ethernet	1 x 10/100/1000 Mbps Ethernet (M12 X-coded)
Display	N/A
Audio	N/A
Storage	1 x mSATA 1 x 2.5" SATA HDD (9.5 mm height)
Expansion	1 x Full-size PCI Express Mini Card slot with mSATA 1 x Full-size PCI Express Mini Card slot with SIM
Others	1 x DC power connector (M12)
Touchscreen	Projected capacitive multi-touch
Enclosure	Stainless type 316
Power Supply	12 VDC or 19 to 24 VDC in cable M12 female 5P
Power Comsumption	36W
Watchdog Timer	255 levels, 1 to 255 sec
Operating Temperature	0°C to +50°C (32°F to +122°F)
Relative Humidity	20% - 90% @40°C; non-condensing
Vibration	2G, 5 - 500Hz, random for SSD
Dimensions (W x D x H)	283.1 x 239.5 x 55.2 mm (11.15" x 9.43" x 2.17")
Weight (net/gross)	3.47 kg (7.65 lb)/5.18kg (11.42 lb)
Certifications	CE
EOS	Windows® 10
Mounting	Suspension VESA mount

GOT810-316-C (P/N-E22B810107)
10.4" IP66 & IP69K stainless steel touch panel computer with projected capacitive touch, Intel® Celeron® N3350 onboard, XGA 450 nits LCD, and water-proof power cable (1.8 m)
594B8122100E
Water-proof COM cable (1.8 m)
594B8122820E
USB cable M12-8P-F/2 x type A (1.8 m)
594B8152710E
Water-proof LAN cable (1.8 m)
50966224010E
Adapter 24V 90W, M12 A-code 5P FSP090AAAN3
594B8120B30E
DC in cable M12 female 5P 180cm w/o ACC
