GOT315A-ELK-WCD

LCD Panel	15.6" WXGA TFT LCD 400 nits 1366 x 768 pixels
CPU	Intel® Celeron® processor J6412 (TDP 10W) (Elkhart Lake)
Chipset	SoC integrated
System Memory	1 x 260-pin DDR4 SO-DIMM, up to 32GB
BIOS	AMI
COM	1 x RS-232/422/485
USB	4 x USB 3.2 Gen2 (10 Gbps)
Ethernet	1 x RJ-45 2.5Gb Base-T Ethernet (Intel® I226-LM with TSN) 1 x RJ-45 1Gb Base-T Ethernet (Intel® I210-AT)
Display	1 x HDMI 1.4 1 x VGA
Audio	1 x Line-in/out
Storage	1 x mSATA 1 x 2.5” SATA SSD (7 mm or 9.5 mm height; removable)
Expansion	1 x Full-size PCI-Express Mini Card slot (PCIe/SATA + USB) 1 x M.2 Key E 2230 (for Wi-Fi)
Others	TPM 2.0 1 x Flexible I/O (default 2 x RS-232) 1 x Switch for power on/off (ATX) 1 x Remote power switch 1 x AT/ATX switch (DC type only) 1 x Grounding hole (DC version)
Touchscreen	Projected capacitive multi-touch
Front Bezel	IP65 front bezel
Power Supply	9 to 36VDC 1x terminal block
Power Comsumption	70.8W
Watchdog Timer	255 levels, 0 to 255 sec.
Operating Temperature	-10°C to 50°C (+14°F to +122°F)
Relative Humidity	20% to 90% @ +40°C; non-condensing
Vibration	1G, 5 to 500Hz, random for 2.5" SATA SSD
Dimensions (W x D x H)	409.18 x 59.4 x 265.18 mm (16.1" x 2.3" x 10.4")
Weight (net/gross)	5.07 kg (11.17 lb)/ 7.11 kg (15.66 lb)
Certifications	CE, EN 61000-6-2, EN 61000-6-4, and FCC Class A
EOS	Windows® 10 IoT, Windows® 11 IoT
Mounting	Wall mount kit Panel mount kit

GOT315A-ELK-WCD (P/N-E22B315A00)
15.6" WXGA TFT fanless touch panel computer with Intel® Celeron® processor J6412, projected capacitive multi-touch screen, and 9 to 36 VDC terminal block with small Phoenix connector 4G LTE kit
Wi-Fi kit
RFID kit
Barcode scanner kit
881231770A0E
Wall mount kit
50966224010E
Adaptor 24V/120W, wire only, FSP120-AAAN3
882B315A1A0E
Panel mount kit
E392902101
AX92902+AX93287 full-size PCI Express Mini Module with Gigabit LAN
E392903100
AX92903 full-size PCI Express Mini Module with CAN Bus
E392904101
AX92904 full-size PCI Express Mini Module with 32-bit DIO
E392906100
AX92906 full-size PCI Express Mini Module with COM
E392918102
AX92918 full-size PCI Express Mini Module with 2 Gigabit LAN
