GOT821A-TGL-WCD

LCD Panel	21.5" FHD TFT LCD 400 nits 1920 x 1080 pixels
CPU	Intel® Core™ i5-1145G7E 2.6 GHz or Celeron® 6305E (Tiger Lake)
Chipset	SoC integrated
System Memory	1 x 260-pin DDR4-3200 SO-DIMM, up to 32GB
BIOS	AMI
COM	2 x RS-232/422/485 (default RS-232, A-coded)
USB	4 x USB 2.0 (A-coded)
Ethernet	1 x 2.5GBASE-T Ethernet with Intel® I225 (TSN and X-Coded)
Display	N/A
Audio	N/A
Storage	1 x 2.5" SATA SSD/HDD (9.5mm height)
Expansion	1 x M.2 Key E 2230 slot (with PCIe x1 and USB 2.0 supported)
Others	TPM 2.0 onboard
Touchscreen	Projected capacitive multi-touch
Enclosure	Stainless steel (SUS) 304 or 316 (optional)
Power Supply	1 x DC power connector (M12) 12 to 24 VDC
Power Comsumption	78.7W
Watchdog Timer	255 levels, 1 to 255 sec.
Operating Temperature	-20°C to +50°C (-4°F to +122°F)
Relative Humidity	10% - 95% @ +40°C, non-condensing
Vibration	1G, 5 - 500Hz, random for 2.5" SSD
Dimensions (W x D x H)	552 x 55 x 338.4 mm (21.73" x 2.2" x 13.33")
Weight (net/gross)	9.0 kg (19.84 lb) /12 kg (26.46 lb)
Certifications	CE, EN 61000-6-2, EN 61000-6-4, and FCC Class A C1D2 (optional)
EOS	Windows® 10 IoT, Windows® 11 IoT
Mounting	VESA mount

GOT821A-TGL-WCD (P/N-E22B821A00)
21.5" FHD fanless IP66 & IP69K-rated stainless steel touch panel computer with Intel® Core™ i5-1145G7E, projected capacitive touch screen, 400 nits LCD, and 12 to 24 VDC power input
